•Dimensions: 179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33″)
•Weight: 180 g (6.35 oz)
•Power Supply: 24V, 0.5A Gigabit PoE Supply (NOT INCLUDED)
•Max. Power Consumption: 8.5W
•Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
•Gain: 13 dBi
•Networking Interface: 10/100/1000 Mbps Ethernet Port
•Channel Bandwidths: 10/20/30/40/50/60/80 MHz
•Processor: Specs Atheros MIPS 74Kc, 560 MHz
•Memory: 64 MB DDR2
•Cross-pol Isolation: 20 dB Minimum
•Max. VSWR: 1.8:1
•Beamwidth: 45° (H-pol) / 45° (V-pol) / 45° (Elevation)
•Polarization: Dual Linear
•Enclosure: Outdoor UV Stabilized Plastic
•LEDs: (1) Power
•Mounting: Pole-Mount (Kit Included)
•Operating Temperature: -40 to 70° C (-40 to 158° F)
•Operating Humidity: 5 to 95% Noncondensing
•RoHS Compliance: Yes
•ESD/EMP Protection: ±24kV Contact/Air
•Shock & Vibration: ETSI300-019-1.4
•Certifications: CE, FCC, IC
•Operating Frequency (MHz): 5150 – 5875
•Management Radio (MHz): 2412 – 2472
