Mobilus ryšys
Mobilus modulis4G (LTE) – Cat 12 up to 600 Mbps, 3G – up to 42 Mbps
SIM/mobile module switch2 SIM cards, auto switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail
StatusasSignal strength, SINR, RSRP, RSRQ, Bytes sent/received, connected band, carrier aggregation, IMSI, ICCID,
SMSSMS status, SMS configuration, send/read SMS via HTTP POST/GET, Email to SMS, SMS to Email, SMS to HTTP, SMS to SMS, SMS auto replay
Black/White list (planned)Operator black/white list
Multiple PDNPossibility to use different PDNs for multiple network access and services
Band managementBand lock, Used band status display
APNAuto APN
Bridge modeDirect connection (bridge) between mobile ISP and device on LAN

Bevielis ryšys
Belaidžio ryšio režimas802.11b/g/n/ac Wave 2 (WiFi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO), 802.11r fast transition, Access Point (AP), Station (STA)
Wifi apsaugaWPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK, WEP; AES-CCMP, TKIP, Auto Cipher modes, client separation
ESSIDESSID stealth mode
WiFi naudojotaiup to 150 simultaneous connections
Belaidžio ryšio prieeigaCaptive portal (Hotspot), internal/external Radius server, built in customizable landing page

Tinklas
WAN1 x WAN port (can be configured as LAN) 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
LAN4 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX

Internetas
MaršrutasStatic routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP)
Interneto protokolaiTCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet client, SNMP, MQTT, Wake on LAN (WOL), DLNA
VoIP praėjimo paramaH.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
Ryšio stebėjimasPing Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
UgniasienėPort forwards, traffic rules, custom rules
DHCPStatic and dynamic IP allocation, DHCP Relay, Relayd
QoS / Smart Queue Management (SQM)Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e
DDNSSupported >25 service providers, others can be configured manually
Tinklo atsarginės kopijosVRRP, Mobile, Wired and WiFi WAN options, each of which can be used as an automatic Failover
Load balancingBalance Internet traffic over multiple WAN connections
SSHFSPossibility to mount remote file system via SSH protocol

Saugumas
AutentifikavimasPre-shared key, digital certificates, X.509 certificates
UgniasienėPre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T
Įsilaužimo prevencijaDDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
VLANPort and tag based VLAN separation
Mobile quota controlCustom data limits for both SIM cards
WEB filterBlacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only
Prieigos kontrolėFlexible access control of TCP, UDP, ICMP packets, MAC address filter

VPN
OpenVPNMultiple clients and a server can run simultaneously, 12 encryption methods
OpenVPN EncryptionDES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC
IPsecIKEv1, IKEv2, with 5 encryption methods for IPsec (DES, 3DES, AES128, AES192, AES256)
GREGRE tunnel
PPTP, L2TPClient/Server instances can run simultaneously, L2TPv3 support
StunnelProxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code
DMVPNMethod of building scalable IPsec VPNs
SSTPSSTP client instance support
ZeroTierZeroTier VPN client support
WireGuardWireGuard VPN client and server support

Nustatymai
WEB UIUpdate FW from file, check FW on server, configuration profiles, configuration backup
FOTAUpdate FW/configuration from server
RMSUpdate FW/configuration for multiple devices at once
Nustatymų įsiminimasUpdate FW without losing current configuration

USB
Duomenų perdavimasUSB 2.0
NadojimasSamba share, USB-to-serial
Išoriniai įrenginiaiPossibility to connect external HDD, flash drive, additional modem, printer
Vidinės atminties formatasFAT, FAT32, NTFS

Išėjimai/įėjimai
Įvestis1 x Digital Input, 0 – 6 V detected as logic low, 8 – 30 V detected as logic high
Išvestis1 x Digital Output, Open collector output, max output 30 V, 300 mA
ĮvykiaiSMS, Email, RMS
I/O jugglerAllows to set certain I/O conditions to initiate event

Sistemos parametrai
Jungtys4 pin industrial DC power socket
Įeinančios įtampos diapazonas9 – 50 VDC, reverse polarity protection, voltage surge/transient protection
PoE (passive)Passive PoE. Possibility to power up through LAN1 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards
Energijos sunaudojimasIdle: <4 W, Max: <22 W

Fizinės sąsajos(PORTS, LEDS, ANTENNAS, BUTTONS, SIM)
Tinklas5 x RJ45 ports, 10/100/1000 Mbps
I/Os1 x Digital Input, 1 x Digital Output on 4 pin power connector
LED indikatoriai2 x connection status LEDs, 3 x connection strength LEDs, 10 x Ethernet port status LEDs, 4 x WAN status LEDs, 1x Power LED, 2 x 2.4G and 5G WiFi LEDs
SIM2 x SIM slots (Mini SIM – 2FF), 1.8 V/3 V, external SIM holders
Sistemos parametrai1 x 4 pin DC connector
Antennas4 x SMA for LTE, 2 x RP-SMA for WiFi, 1 x RP-SMA for Bluetooth, 1 x SMA for GNNS
USB1 x USB A port for external devices
PerkrovimasReboot/User default reset/Factory reset button
Kita1 x Grounding screw
