- Kamera
- Sensorius1/2.7″ progressive scan CMOS
- Maks. rezoliucija2560 × 1920
- Min. apšvietimasColor: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Užrakto greitis1/3 s to 1/100,000 s
- Diena & NaktisIR cut filter
- Kampo keitimasPan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
- Lęšis
- Lęšio tipasVarifocal lens, motorized lens, 2.8 to 12 mm
- FOV2.8 to 12 mm: horizontal FOV 97° to 30°, vertical FOV 70° to 22.3°, diagonal FOV 128° to 37°
- Lęšio montavimasØ14
- Rainelės tipasFixed
- DiafragamaF1.6
- Apšvietimas
- Papildomo apšviešimo tipasIR
- Papildomo apšvietimo diapazonasUp to 50 m
- IR bangos ilgis850 nm
- Vaizdas
- Pagrindinis srautas
50 Hz: 20 fps (2560 × 1920)
25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 20 fps (2560 × 1920)
30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
- Antrinis srautas
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Vaizdo suspaudimas
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
- Vaizdo bitų greitis32 Kbps to 16 Mbps
- H.264 tipasBaseline Profile/Main Profile/High Profile
- H.265 tipasMain profile
- ROI1 fixed region for main stream
- Tinklas
- ProtokolaiTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
- Tiesioginis vaizdo žiūrėjimasUp to 6 channels
- APIOpen Network Video Interface, ISAPI
- User/Host
Up to 32 users. 3 levels: administrator, operator and user
3 user levels: administrator, operator, and user
- KlientasiVMS-4200, Hik-Connect
- Naršyklė
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
- Nuotrauka
- Nuotraukos nustatymaiSaturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
- Diena/Naktis režimasAuto, Schedule, Day, Night
- WDR120 dB
- Nuotraukų pagražinimasBLC, 3D DNR
- Sąsaja
- Interneto sąsaja1 RJ45 10 M/100 M self-adaptive Ethernet port
- Vidinė atmintisBuilt-in memory card slot, support microSD card, up to 256 GB
- Perkrovimo mygtukasYes
- Funkcijos
- Pagrindinės funckcijosMotion detection, video tampering alarm, exception
- SąsajaUpload to FTP, notify surveillance center, send email, upload to memory card, trigger recording, trigger capture
- Pagrindinis
- Maitinimas
12 VDC ± 25%, 0.9 A, max. 10.8 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W
- DydisØ105 mm × 244.4 mm (Ø4.1″ × 9.6″)
- Pakuotės dydis315 mm × 137 mm × 141 mm (12.4″ × 5.4″ × 5.6″)
- Approx. 715 g (1.6 lb.)
- Svoris su įpakavimuApprox. 1125 g (2.5 lb.)
- Sandėliavimo sąlygos-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Darbo sąlygos-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- KalbaEnglish, Ukrainian
- Pagrindinės funkcijosAnti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Patvirtinimai
- EMC
FCC SDoC: 47 CFR Part 15, Subpart B;
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011+A1: 2014;
RCM: AS/NZS CISPR 32: 2015;
IC VoC: ICES-003: Issue 7;
KC: KN 32: 2015, KN 35: 2015
- Saugumas
UL: UL 62368-1;
CB: IEC 62368-1:2014+A11;
CE-LVD: EN 62368-1:2014/A11:2017;
BIS: IS 13252(Part 1):2010/ IEC 60950-1: 2005
- Aplinkosauga
CE-RoHS: 2011/65/EU;
WEEE: 2012/19/EU;
Reach: Regulation (EC) No 1907/2006
- ApsaugaIP67: IEC 60529-2013
