- Kamera
- Sensorius1/2.7″ Progressive Scan CMOS
- Maks. rezoliucija1920 × 1080
- Min. apšvietimasColor: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Užrakto greitis1/3 s to 1/100,000 s
- Diena & Naktis IR Cut Filter
- Kampo keitimasPan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
- Lęšis
- FOV
2.8 mm: horizontal FOV 111.6°, vertical FOV 59.1°, diagonal FOV 133.9°
4 mm: horizontal FOV 91.5°, vertical FOV 46.1°, diagonal FOV 109.8°
6 mm: horizontal FOV 56°, vertical FOV 29.8°, diagonal FOV 65.3°
- Lęšio montavimasM12
- FokusavimasFixed
- DiafragamaF1.6
- Apšvietimas
- Papildomo apšvietimo diapazonasUp to 30 m
- IR bangos ilgis850 nm
- Vaizdas
- Pagrindinis srautas
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
- Antrinis srautas
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
- Vaizdo suspaudimas
Main stream: H.265+/H.265//H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
- Vaizdo bitų greitis32 Kbps to 8 Mbps
- H.264 tipasBaseline Profile/Main Profile/High Profile
- H.265 tipasMain Profile
- ROISupport 1 fixed region for main stream
- Internetas
- ProtokolaiTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
- Tiesioginis vaizdo žiūrėjimasUp to 6 channels
- APIOpen Network Video Interface, ISAPI
- User/HostUp to 32 users. 3 levels: administrator, operator and user
- Vidinė atmintisSupport Micro SD/SDHC/SDXC card (256 GB), local storage and NAS (NFS, SMB/CIFS), ANR
- KlientasiVMS-4200, Hik-Connect, Hik-Central
- Naršyklė
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
- Nuotrauka
- Nuotraukos nustatymaiRotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
- Diena/Naktis režimasDay, Night, Auto, Schedule
- Nuotraukų pagražinimasBLC, 3D DNR
- WDR120 dB
- Sąsaja
- Interneto sąsaja1 RJ45 10 M/100 M self-adaptive Ethernet port
- Vidinė atmintisBuilt-in Micro SD slot, up to 256 GB
- Garsas-S: 1 input (line in), 1 output (line out)
- Signalizacija-S: 1 input, 1 output (max. 12 VDC, 30 mA)
- Perkrovimo mygtukasYes
- Funkcijos
- Pagrindinės funckcijosMotion detection,video tampering alarm
- Išmaniosios funkcijosLine crossing detection, intrusion detection
- SąsajaUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture
- Pagrindinis
- Sistemos parametrai
12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.20 A to 0.15 A, max. 6.5 W
- DydisØ110.8 mm × 84.7 mm (Ø 4.4″ × 3.3″)
- Pakuotės dydis135 mm × 135 mm × 110 mm (5.3″ × 5.3″ × 4.3″)
- Approx. 497 g (1.1 lb.)
- Svoris su įpakavimuApprox. 597 g (1.3 lb.)
- Darbo sąlygos-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
- Sandėliavimo sąlygos-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
- Kalba
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak,
French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian,
Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai,
Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Pagrindinės funkcijosOne-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Patvirtinimai
- EMC
FCC (47 CFR Part 15, Subpart B)
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014)
RCM (AS/NZS CISPR 32: 2015)
IC (ICES-003: Issue 7)
KC (KN32: 2015, KN35: 2015)
- Saugumas
UL (UL 62368-1)
CB (IEC 62368-1: 2014+A11)
CE-LVD (EN 62368-1: 2014/A11: 2017)
LOA (IEC/EN 60950-1)
BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005)
- Aplinkosauga
CE-RoHS (2011/65/EU); WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
- Apsauga
IP67 (IEC 60529-2013)
IK10 (IEC 62262: 2002)
