- Lęšis
- FOVHorizontal field of view: 96.7° to 31.6° (Wide-Tele), Vertical field of view: 51.1° to 17.7° (Wide-Tele) , Diagonal field of view: 115.1° to 36.3° (Wide-Tele)
- Artinimo greitisApprox. 2 s (optical lens, wide-tele)
- Darbinis atstumas10 mm to 1500 mm (wide-tele)
- Diafragmos diapazonasF1.6 to F2.7
- Židinio nuotolis2.8 mm to 12 mm, 4× optical zoom
- Nuotrauka
- Nuotraukos pagražinimai3D DNR, EIS, Regional Exposure, Regional Focus
- Antrinis srautas50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
- Maks. rezoliucija2560 × 1440
- Pagrindinis srautas50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 24fps (2560 × 1440), 30fps(2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
- Trečiasis srautas50Hz: 25fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (1280 × 720, 704 × 480, 640 × 480, 352 × 240)
- Tinklas
- Tinklo saugyklaBuilt-in memory card slot, support microSD/SDHC/SDXC, up to 256 GB; NAS (NFS, SMB/ CIFS), ANR
- ProtokolaiIPv4/IPv6, HTTP, HTTPS, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
- APIONVIF (Profile S, Profile G, Profile T), ISAPI, SDK
- Tiesioginio vaizdo žiūrėjimasUp to 20 channels
- User/HostUp to 32 users,3 levels: Administrator, Operator and User
- KlientasiVMS-4200, Hik-Central, Hik-Connect
- Interneto naršyklėsIE 8 to 11,Chrome 31.0+, Firefox 30.0+, Edge 16.16299+
- Apsaugos priemonėsUser authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
- Signalizacijos sąsajaAlarm actions, such as Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
- Sąsaja
- Garso įvestis1-ch audio input (mic in/line in) , 1 built-in microphone
- Garso išvestis1-ch audio output
- Tinklo sąsaja1 RJ45 10 M/100 M Ethernet, PoE
- Suspaudimas
- H.264+Yes
- H.265+Yes
- H.264 tipasBaseline Profile/Main Profile/High Profile
- Vaizdo suspaudimasMain Stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG
- Vaizdo bitų greitis32 Kbps to 16384 Kbps
- Garso suspaudimasG.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
- Garso bitų greitis64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 192 Kbps(MP2L2)
- SVCYes
- Kameros moduliai
- Sensorius1/3″ progressive scan CMOS
- Min. apšvietimasColor: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR
- Baltos spalvos balansasAuto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
- Užrakto greitis50Hz: 1/1 s to 1/30,000 s,60Hz: 1/1 s to 1/30,000 s
- Diena&NaktisIR cut filter
- Skaitmeninis priartinimas16×
- Privatumo kaukės24 programmable privacy masks
- Fokusavimo rėžimaiAuto/Semi-automatic/Manual
- WDR120 dB WDR
- Papildoma šviesa
- IR distancija20 m
- Išmanus IRYes
- PTZ
- Judėjimo kampas (Pan)0° to 355°
- Pan greitisConfigurable, from 0.1°/s to 100°/s, ,Preset speed: 100°/s
- Judėjimo kampas(Tilt)From 0° to 90°
- Tilt greitisConfigurable, from 0.1°/s to 100°/s,Preset Speed: 100°/s
- Proporcingas prirtinimasYes
- Išankstinės veikimo zonos 300
- Atmintis išjungus prietaisąYes
- Išmaniosios funkcijos
- Paprastos funkcijosMotion Detection, Video Tampering Detection, Exception
- Išmaniosios funkcijosFace detection, intrusion detection, line crossing detection, region entrance detection, region exiting detection, object removal detection, unattended baggage detection, audio exception detection
- Išmanus vaizdo įrašymasANR (Automatic Network Replenishment), Dual-VCA
- ROIMain stream, sub-stream, and third stream respectively support four fixed areas.
- Pagrindinis
- MedžiagaAluminum alloy, PC, PC+ABS
- DydisΦ 130.7 mm × 101.7 mm (Φ 5.15″ × 4.00″) Approx. 0.53 kg (1.17 lb)
- ApsaugaIP66 standard, IK 10, surge protection, ±2kV Line to Gnd, ±1kV Line to Line, IEC61000-4-5
- Maitinimas12 VDC, 1.5 A (Max. 10.9 W, including Max. 4.2 W for IR)PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 12.2 W, including max. 4.2 W for IR)
- Darbinės sąlygos (temperatūra)-20°C to 60°C (-4°F to 140°F)
- Darbinės sąlygos (drėgmė)≤ 90%
