- Kamera
- Sensorius1/1.8″ Progressive Scan CMOS
- Maks. rezoliucija1920 × 1080
- Min. apšvietimas
Color: 0.0005 Lux @ (F1.2, AGC ON);
B/W: 0.0001 Lux @ (F1.2, AGC ON)，0 Lux with IR
- Užrakto greitis1 s to 1/100,000 s
- Diena & Naktis
IR cut filter
Blue glass module to reduce ghost phenomenon
- Lęšis
- FOV
2.8 to 12 mm, horizontal FOV: 114.5° to 41.8°, vertical FOV: 59.3° to 23.6°, diagonal FOV: 141.1° to 48°
8 to 32 mm, horizontal FOV: 42.5° to 15.1°, vertical FOV: 23.3° to 8.64°, diagonal FOV: 49.6° to 17.3°
- FokusavimasAuto, semi-auto, manual
- Rainelės tipasP-iris
- Diafragama
2.8 to 12 mm: F1.2 to F2.5
8 to 32 mm: F1.7 to F1.73
- DORI
- DORI
Wide:
2.8 to 12 mm: D: 45 m, O: 17.9 m, R: 9 m, I: 4.5 m
8 to 32 mm: D: 112.7 m, O: 44.8 m, R: 22.6 m, I: 11.3 m
Tele:
2.8 to 12 mm: D: 111.8 m, O: 44.3 m, R: 22.4 m, I: 11.2 m
8 to 32 mm: D: 300 m, O: 119.0 m, R: 60 m, I: 30 m
- Apšvietimas
- Papildomo apšviešimo tipasIR
- Papildomo apšvietimo diapazonas
2.8 to 12 mm: 50 m
8 to 32 mm: 100 m
- Išmanus papildomas apšvietimasYes
- IR bangos ilgis850 nm
- Vaizdas
- Pagrindinis srautas
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
- Antrinis srautas
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
- Trečias srautas
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
- Ketvirtas srautas
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
- Penktasis srautas
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
- Vaizdo suspaudimas
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream/Third stream/Fourth stream/Fifth stream: H.265/H.264/MJPEG
- Vaizdo bitų greitis32 Kbps to 8 Mbps
- H.264 tipasBaseline Profile/Main Profile/High Profile
- H.265 tipasMain Profile
- Bitų greičio kontrolėCBR/VBR
- SVCH.265 and H.264 encoding
- ROI4 fixed regions for each stream
- Tikslinis apkarpymasYes
- Garsas
- Garso tipasMono sound
- Garso suspaudimasG.711/G.722.1/G.726/MP2L2/PCM/AAC/MP3
- Garso bitų greitis64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC)/8 to 320 Kbps (MP3)
- Garso atrankos dažnis8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz
- Pašalinių garsų šalinimasYes
- Tinklas
- ProtokolaiTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
- Tiesioginis vaizdo žiūrėjimasUp to 20 channels
- APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
- User/HostUp to 32 users. 3 user levels: administrator, operator and user
- SaugumasPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
- Vidinė atmintis
NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported
- KlientasiVMS-4200, Hik-Connect, Hik-Central
- Naršyklė
Plug-in required live view: IE8+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+
Local service: Chrome 41.0+, Firefox 30.0+
- Nuotrauka
- Nuotraukos parametrų keitiklisYes
- Nuotraukos nustatymaiSaturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
- Diena/Naktis režimasDay, Night, Auto, Schedule, Alarm Trigger, Video Trigger
- WDR140 dB
- SNR≥ 52 dB
- Nuotraukų pagražinimasBLC, HLC, Defog, 3D DNR
- Nuotraukos perdangaLOGO picture can be overlaid on video with 128 × 128 24bit bmp format
- Vaizdo stabilizavimasEIS
- Sąsaja
- Vaizdo išvestis1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
- Interneto sąsaja1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
- Vidinė atmintisBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
- GarsasWith -Y: 1 input (line in), 1 output (line out), 3.5 mm connector
- Signalizacija2 input, 2 outputs (max. 24 VDC, 1 A)
- RS-485With -Y: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
- Perkrovimo mygtukasYes
- GaliaWith -Y: 12 VDC, max. 100 mA
- Wiegand/P-Y: 1 Wiegand (CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit)
- Funkcijos
- Pagrindinės funckcijosMotion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, abnormal reboot, HDD full, HDD error), video quality diagnosis, vibration detection
- Išmaniosios funkcijos
Intrusion detection, scene change detection, audio exception detection, defocus detection
Line crossing detection, up to 4 lines configurable Intrusion detection, up to 4 regions configurable
Region entrance detection, up to 4 regions configurable
Region exiting detection, up to 4 regions configurable
- SąsajaUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture
- Išmaniosios funkcijos
- Perimetro apsauga
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types
- Kelių eismo ir transporto priemonių aptikimas
Blocklist and allowlist: up to 10,000 records
Captures vehicle that has no license plate
Support license plate recognition of motorcycles (only in checkpoint scenario)
Support vehicle attribute detection, including vehicle type, color, brand, etc. (City Street mode is recommended.)
- Meta duomenysMetadata of road traffic is supported.
- Pagrindinis
- Maitinimas
12 VDC ± 20%, 1.19 A, max. 14.28 W, three-core terminal block
PoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V), 0.396 A to 0. 295 A, max. 16.8 W
- Dydis
Without -Y: Ø144 × 347 mm (Ø5.7″ × 13.7″)
With -Y: Ø140 × 351 mm (Ø5.5 × 13.8″)”
- Įpakavimo dydis405 × 190 × 180 mm (15.9″ × 7.5″ × 7.1″)
- Approx. 1950 g (4.2 lb.)
- Svoris su įpakavimuApprox. 3070 g (6.7 lb.)
- Sandėliavimo operacija-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Darbo sąlygos-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
- Kalba33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil),Ukrainian
- Pagrindinės funkcijosAnti-flicker, 5 streams, EPTZ, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
- ŠildytuvasYes
- Patvirtinimai
- EMC
FCC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EEN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC (ICES-003: Issue 7);
KC (KN 32: 2015, KN 35: 2015)
- Saugumas
UL (UL 62368-1);
CB (IEC 62368-1:2014+A11);
CE-LVD (EN 62368-1:2014/A11:2017);
BIS (IS 13252(Part 1):2010/ IEC 60950-1 : 2005);
LOA (IEC/EN 60950-1)
- Aplinkosauga
CE-RoHS (2011/65/EU);
WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
- ApsaugaIK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
- Apsauga nuo korozijosWith -Y: NEMA 4X(NEMA 250-2018)
- AutomatikaEN50121-4
- KitaPVC FREE
