- Architektūra
- ProcesoriusQCA9563+QCA9886+QCA8334
- RAM64MB
- Flash atmintis16MB
- Radio signalas802.11a/n/ac radio Speed up to 867 Mbps Frequency Range:5.1-5.8GHz Tx Power up to 26dBm Rx Sensitivity 300M:-71dBm@10% PER 54M:-75dBm@10% PER 1M:-95dBm@10% PER
- Antena
- Antena16dBi dual-polarized directional antenna Beamwidth(HPBW): Horizontal: 60°, Vertical: 30°
- Fiziniai parametraiDimension:260x100x60mm Weight:0.4kg Enclosure: Weatherproof Plastic ESD Protection：8kV Lightning Protection：4kV Working Temp：-40~65℃ Storage Temp：-40~85℃ Working Humidity：10%~95% non-condensing
- Sąsajos1x 10/100/1000 Base-T Ethernet (RJ45 with Passive PoE) Reset
- Pagrindinis
- Galia24VDC, 0.5A
- LEDPower: On/Off LAN:On/Off/Flashing RSSI Signal: 1,2,3
- SertifikataiCE, RoHS
- Energijos sunaudojimas10W
- Pakuotės turinysWIS-Q800P Quick Setup Guide Power Adapter with Passive PoE Mounting kits
